Product Detail

K-TEK-M76-HP-3

Category: Force Sensing Resistor
Key Number: 3 keys + 1 Hula Point button
Key Travel: 1.50mm
Interface: USB/PS2 optional
Key Switch: Carbon-on-gold
Protection Level: IP65
Mounting Solution: Rear panel mount
Operating Temperature: -20ºC to +65ºC
Application: Vehicle, aerospace, naval, defense, maritime, Radar, console, UAV ground station, medical etc.
Description
Download

DESCRIPTION: IP65 dynamic rated waterproof & rugged Force Sensing Resistor pointing device integrated in one-piece compact seamless silicone cover for fast and accurate cursor position, with 3 mouse buttons for left and right clicking, middle wheel function, and with mounting holes along for easy mounting & sealing, which is good for much oil, water, sand etc application or gloves are needed when operation. USB interface, military level optional.

Dimensions: 76.0mm x 32.6mm x 8.6mm (L x W x H)


MECHANICAL DATA

Keys

3 keys + 1 Hula Point button

Key top style

One silicone coat with rubber keys with very good tactile feeling.

Key travel

1.50mm

Actuation Force

1.5N±0.2N (pressure point)

Switch life

more than 5 million of operations

G.W.

0.10KGs

ELECTRICAL DATA

Supply Voltage

DC +5V±5%

Current Rating

15mA

Power

1.0W

Lifespan

> 5 years

Switch Contact Material

Carbon-on-Gold key switch technology PCB

Interface

PS2, USB available

Cable length

Standard 2.0m, customized length available

OS

All Windows, Linux, Unix, Mac OSX, Vxworks, Android, (U-cos--To be confirmed).

ENVIRONMENTAL ADAPTABILITY

Operating temperature

-20℃ to +65

Storage temperature

-30℃ to +75

Operating RH

100%

Atmospheric pressure

60-106Kpa

Saline mist

96 hours, IEC 60512-6

Damp heat test at +40℃

21 days, IEC 60512-6

Dry heat test at +85℃

10 days, IEC 60512-6

RELIABILITY

RoHS, CE, FCC, MIL-STD-461G (EMC, EMI, EMS, ESD) and MIL-STD-810F (wide temperature, shock, salt mist, vibration, fungus, humidity) optional

Protection Level

IP65

Key Lifespan

>5 million actuations

MTBF

>20000H

MTTR

<30min

APPLICATIONS

Vehicle, aerospace, naval, defense, maritime, Radar, console, portable rugged laptop, UAV ground station etc.


K-TEK-M76-HP-3--mechanical drawing
